Place of Origin: | Guang Zhou China |
---|---|
Brand Name: | RIBO |
Certification: | Certificate of Quality |
Model Number: | RiBo-10CR600 |
Minimum Order Quantity: | 1 PC |
Price: | Negotiable |
Packaging Details: | Main blowing machine and the preform feeding system are packed by the wooden pallets |
Delivery Time: | 90-120 days |
Payment Terms: | T/T, L/C |
Supply Ability: | 100 PCS |
Blow Molding Type: | Stretch Blow Molding | High Efficient: | 20000 BPH |
---|---|---|---|
Automatic: | Yes | Energy Consumption: | Saving Energy Can Be Up To 50% |
Use For: | Variable PET Bottle Of Water , Drink , Food , Edible Oil , Daily Chemical After-sales Service Provided | After-sales Service Provided: | Engineers Available To Service Machinery Overseas , Online Support , Field Maintenance And Repair Service , Video Technical Support , Field Installation |
High Light: | 20000 BPH Preform Bottle Blowing Machine,Preform Bottle Blowing Machine Linear Production,20000 BPH Preform Blowing Machine |
11. Technical Parameter.
Items | Unit | Model | |
RiBo-10CR600 | |||
Molding Spec. | Preform Pitch | mm | 76 |
Preform Heating Pitch | mm | 38 | |
No.of Cav. | cav. | 10 | |
Container Spec. | Max.Container Volume | L | 0.7 |
Neck Diameter Range | mm | 18~30 | |
Max.Containr Diameter | mm | 70 | |
Max.Containr Height | mm | 240 | |
※※Theoretical Output | bph | 20000 | |
Power Spec. | Rated Power | KW | 123 |
Power Consumption | KW | 46~56 | |
Compressor Spec. | Blowing Pressure | Mpa | 2.5~3.2 |
Air Consuming | m3/min | 10 | |
Main Machine Spec. | Size | mm | 7479*3408*3200 |
Weight | Kg | 9500 | |
*Due to continuous technical development specification would be improved without prior notice.
*Special designs correspond to customers needs.
