| Place of Origin: | Guangzhou China |
|---|---|
| Brand Name: | RiBo |
| Model Number: | BLMS-9000 |
| Minimum Order Quantity: | 1 PC |
| Price: | Negotiable |
| Packaging Details: | Main machine will be packed by wooden pallets |
| Delivery Time: | 60 days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 80 PCS/Year |
| Voltage: | 380V/50HZ | Warranty: | 1 Year |
|---|---|---|---|
| Blow Moulding Type: | Stretch Blow Moulding | Application: | Beverage Bottle/oil Botlte/shampoo Bottle |
| Plastic Processed: | PET | Cavity: | 2/4/6 Cavity |
| Use: | Making PET Bottle | Output: | 9000~10000BPH |
| High Light: | 50HZ Small Plastic Blow Molding Machine,380V Small Plastic Blow Molding Machine,380V high speed blow molding machine |
||
Small Water Bottle Moulding Machine , Energy Saving High Speed Machine
1. This series is widely used for making PET bottles for drinking water, carbonated soft drink, medium temperature filling drink,
milk, edible oil, food, pharmacy, daily chemical……etc.
2. The man-machine interface is highly automated and easy to operate. The compact machine occupies a smaller area.
3. The servo motor is adopted to drive the molding mechanism, triggering off a bottom mold linkage as well. The whole
mechanism works speedy,accurately, stably and flexibly. Meanwhile, it is energy efficient and environmental safe.
4. The thermostatic heating system ensure that the heating temperature of each preform surface and internal is uniform. Hinged
oven holders make it easy for the operators to change infrared tubes and do maintenance.
Machine Technical Parameter
| Items | Unit | Model | |
| BLMS-9000 | |||
| Molding Spec. | Cavity Pitch | mm | 76 |
| Preform Heating Pitch | mm | 76 | |
| No.of Cav. | Cav. | 6 | |
| Container Spec. | Max.Container Volume | L | 0.6 |
| Neck Diameter Range | mm | 18-38 | |
| Max.Containr Diameter | mm | 70 | |
| Max.Containr Height | mm | 240 | |
| ※※Theoretical Output | bph | 10000~9000 | |
| Power Spec. | Rated Power | KW | 88 |
| Power Consumption | KW | 45~55 | |
| Compressor Spec. | Blowing Pressure | Mpa | 2.5~3.2 |
| Air Consuming | m³/min | 7~8 | |
| Whole Machine Spec. | Size | mm | 5191*4864*3200 |
| Weight | Kg | 5500 | |
| Note: Due to continuous technical development specification would be improved without prior notice. | |||
| Special designs correspond to customers needs. | |||
